Thoracic Imaging Archive

Archived case 2 · Jun 4-Jun 11, 2009

Left Upper Lobe Collapse

59 year old female with cough

Images

Radiograph 1 from archived case 2
Figure 1
Radiograph 2 from archived case 2
Figure 2
Radiograph 3 from archived case 2
Figure 3

Diagnosis

Left Upper Lobe Collapse

German “air” and “cresent” - Luftsichel Sign Para-mediastinal / para-aortic lucency LUL displaced from the mediastinum by overinflated superior segment LLL Not to be confused with pneumothorax or pneumomediastinum     Diagnosis: Left Upper Lobe Collapse

Bronchoscopy revealed...

  • an occluding friable endobronchial lesion extending from LUL into the left mainstem

  • paralysis of the left vocal cord

Filed under: Radiology, Medicine/Pulmonary
